Pride Jazzy Ultra Light 20Ah Lithium Battery

The Pride Jazzy Ultra Light 20Ah lithium battery is the 25.2 V 20 Ah (504 Wh) boxed pack, SKU BATHP20020. Westin Healthcare sells it, delivers it, and can swap it in Brampton and the Greater Toronto Area. Pride prints 7 lb on the 20 Ah battery row and a 13-month limited battery warranty. This is one boxed pack, not a pair of 12 V cells.

Who this battery is for

This box is the extended-range spare for the Jazzy Ultra Light. Pride names BATHP20020 / XRFBATHP20020 on the Ultra Light order form. It is not the 10 Ah BATHP20010 travel pack, and it is not the Go Go Carbon BAT2402057. Warehouse code 20AH on a different ERP row is not this SKU.

Bring the old box or a photo of the Model line. Call (905) 451-7743 if the handle or the charge port does not match.

Jazzy Ultra Light 20Ah chemistry and airline listing

Pride's lithium table lists the Jazzy Ultra Light 20 Ah pack at 25.2 V 20 Ah, 504 Wh, and marks it not airline compliant. The 10 Ah pack is the travel battery. Do not check this 20 Ah box as a cabin spare unless the airline writes a waiver. Use only the Pride lithium charger the chair manual names.

The chair range Pride prints with this pack is up to 16.4 miles at 200 lb and 14.4 miles at 300 lb. Terrain and tyre condition change that number.

BATHP20020 specifications

These figures are from Pride's Jazzy Ultra Light specification page, lithium table, and order form INFINFB4705/RevB/23MAR2026, accessed 2026-09-10. The specification tab holds the stored values.

25.2 V lithium-ion. 20 Ah. 504 Wh. About 7 lb. 13-month limited battery warranty. Label on the sourced pack shot prints Model BATHP20020, UN38.3, and a 5 A max charge current. Made as a Pride OEM box.

20 Ah Ultra Light or another Pride lithium: which sibling fits

Stay on BATHP20020 if the old box is the 20 Ah Ultra Light pack. The Go Go Carbon spare is the BAT2402057. The ATTO scooter spare is the Moving Life Standard Flight Battery. A 12 V gel group 24 is the MK 8G24.

The chair itself is the Pride Jazzy Ultra Light.

Delivery and setup in Brampton and the GTA

Westin's own team delivers this battery across Brampton and the Greater Toronto Area. When you want the box swapped at home, we fit the new pack and take the old one for recycle. Book that swap on the battery replacement page or by calling (905) 451-7743.

We have three stores in the Brampton and Toronto area if you would rather bring the old Ultra Light box in. Inside Toronto and the GTA, White-Glove Delivery is described on the shipping policy. Any charge is confirmed on your order.

Related mobility batteries from Westin

• Pride Go Go Carbon Lithium Battery
• Moving Life ATTO Standard Flight Battery
• MK 8A22NF 12V 55AH AGM Battery

Browse batteries for medical equipment and powerchair batteries.

Service and warranty

When a Jazzy Ultra Light pack needs a swap, you call the shop that fitted it. Westin Healthcare has a service and repairs department. Our technicians come to the home or workplace.

Pride warranty

Pride prints a 13-month limited battery warranty on the Ultra Light lithium table. We handle the claim with you.

Frequently asked questions

Can I Take The 20Ah Ultra Light Battery On A Plane?

Pride prints the 20 Ah pack as not airline compliant. The 10 Ah pack is the travel battery. Confirm with the airline. Do not assume a 504 Wh box is cabin-legal.

Is This The Same As Warehouse SKU 20AH?

No. Pride names this box BATHP20020. Warehouse code 20AH is a different ERP row and is not mapped on a Pride sheet. Order BATHP20020 for the Jazzy Ultra Light 20 Ah box.

Do I Need Two Batteries?

No. The Ultra Light runs one boxed lithium pack. A second BATHP20020 is a spare you swap, not a 24 V pair of 12 V cells.

What Charger Do I Use?

Use the Pride off-board lithium charger the Ultra Light manual names. Do not use a lead-acid gel or AGM charger on this pack.

What Is The Warranty?

Pride prints 13 months limited on the Ultra Light battery. Westin Healthcare processes the manufacturer claim.
