Parts finder
Replacement parts for the Leckey Freestander
The exploded view below is numbered. Click a number on the drawing to jump to that part, or search the list. Every price shown is the current online price; anything quoted is priced by our order desk.
Loading the drawing
Freestander Spare Parts - Main Frame & Belts
13 partsExploded view from the manufacturer's parts manual (Freestander Parts Manual). The numbers on the drawing match that manual's parts list. Tell us the number and the model and our order desk will quote the part.
| No. | Part | Qty | Price | Action |
|---|---|---|---|---|
| 1 | Frame (Size 1) ●Manufacturer no. RAT-4-1636 | 1 | Quote | Ask for a quote |
| 1 | Frame (Size 2) ●Manufacturer no. RAT-4-2636 | 1 | Quote | Ask for a quote |
| 1 | Frame (Size 3) ●Manufacturer no. RAT-4-3636 | 1 | Quote | Ask for a quote |
| 2 | 4'' Castor [Single] ● ● ●Manufacturer no. IA13 | 1 | Quote | Ask for a quote |
| 3 | Tray Lower Tube (Size 1) [Single] ●Manufacturer no. RAT-4-1014 | 1 | Quote | Ask for a quote |
| 3 | Tray Lower Tube (Size 2) [Single] ●Manufacturer no. RAT-4-2014 | 1 | Quote | Ask for a quote |
| 3 | Tray Lower Tube (Size 3) [Single] ●Manufacturer no. RAT-4-3014 | 1 | Quote | Ask for a quote |
| 4 | Upright Lower Tube (Size 1) [Single] ●Manufacturer no. RAT-4-1005 | 1 | Quote | Ask for a quote |
| 4 | Upright Lower Tube (Size 2) [Single] ●Manufacturer no. RAT-4-2005 | 1 | Quote | Ask for a quote |
| 4 | Upright Lower Tube (Size 3) [Single] ●Manufacturer no. RAT-4-3005 | 1 | Quote | Ask for a quote |
| 5 | 1-1/2" Ribbed Tube Inserts [4 Pack] ● ● ●Manufacturer no. SF56 | 1 | Quote | Ask for a quote |
| 6 | Footplate (Size 1) ●Manufacturer no. RAT-4-1004 | 1 | Quote | Ask for a quote |
| 6 | Footplate (Size 2) ●Manufacturer no. RAT-4-2004 | 1 | Quote | Ask for a quote |
Exploded view, page 3
13 partsExploded view from the manufacturer's parts manual (Freestander Parts Manual). The numbers on the drawing match that manual's parts list. Tell us the number and the model and our order desk will quote the part.
| No. | Part | Qty | Price | Action |
|---|---|---|---|---|
| 8 | Hip Belt Std (Size 1) -MW ●Manufacturer no. LFS/1/B-XX | 1 | Quote | Ask for a quote |
| 8 | Freestander Pelvic Band (Size 2) -MB ● ●Manufacturer no. LFS/2/B-XX | 1 | Quote | Ask for a quote |
| 8 | Hip Belt Std (Size 3) -MB ● ●Manufacturer no. LFS/3/B-XX | 1 | Quote | Ask for a quote |
| 9 | High Back Strap (Size 1) -MW ●Manufacturer no. LFS/1/D-XX | 1 | Quote | Ask for a quote |
| 9 | High Back Strap (Size 2) -MB ●Manufacturer no. LFS/2/D-XX | 1 | Quote | Ask for a quote |
| 9 | High Back Strap (Size 3) -MB ●Manufacturer no. LFS/3/D-XX | 1 | Quote | Ask for a quote |
| 10 | Upright Upper Tube (Size 1) ●Manufacturer no. RAT-4-1006 | 1 | Quote | Ask for a quote |
| 10 | Upright Upper Tube (Size 2) ●Manufacturer no. RAT-4-2006 | 1 | Quote | Ask for a quote |
| 10 | Upright Upper Tube (Size 3) ●Manufacturer no. RAT-4-3006 | 1 | Quote | Ask for a quote |
| 11 | M8x16 Knob [Single] ● ● ●Manufacturer no. SF41 | 1 | Quote | Ask for a quote |
| 12 | 1 1/8" Dia Ribbed Tube Insert [Single] ● ● ●Manufacturer no. SF55 | 1 | Quote | Ask for a quote |
| 13 | Pole End Protectors -MW -MB ● ● ●Manufacturer no. LFS/1/L5-XX | 1 | Quote | Ask for a quote |
| 14 | Care Kit ● ● ●Manufacturer no. LFS-9500 | 1 | Quote | Ask for a quote |
Freestander Spare Parts - Chest Pad & Laterals
18 partsExploded view from the manufacturer's parts manual (Freestander Parts Manual). The numbers on the drawing match that manual's parts list. Tell us the number and the model and our order desk will quote the part.
| No. | Part | Qty | Price | Action |
|---|---|---|---|---|
| 0 | Chest Pad Full Assembly (Size 1) -MW ●Manufacturer no. RAT-4-1630-XX | 1 | Quote | Ask for a quote |
| 0 | Chest Pad Full Assembly (Size 2) -MB ●Manufacturer no. RAT-4-2630-XX | 1 | Quote | Ask for a quote |
| 0 | Chest Pad Full Assembly (Size 3) -MB ●Manufacturer no. RAT-4-3630-XX | 1 | Quote | Ask for a quote |
| 1 | Chest Pad (Size 1) -MW ●Manufacturer no. RAT-4-1611-XX | 1 | Quote | Ask for a quote |
| 1 | Chest Pad (Size 2) -MB ●Manufacturer no. RAT-4-2611-XX | 1 | Quote | Ask for a quote |
| 1 | Chest Pad (Size 3) -MB ●Manufacturer no. RAT-4-3611-XX | 1 | Quote | Ask for a quote |
| 1 | Chest Pad (Size 3) (Double Thoracic) -MB ●Manufacturer no. RAS-4-3611-XX | 1 | Quote | Ask for a quote |
| 2 | Chest Plate (Size 1) ●Manufacturer no. RAT-4-1637 | 1 | Quote | Ask for a quote |
| 2 | Chest Plate (Size 2) ●Manufacturer no. RAT-4-2637 | 1 | Quote | Ask for a quote |
| 2 | Chest Plate (Size 3) ●Manufacturer no. RAT-4-3637 | 1 | Quote | Ask for a quote |
| 2 | Large Chest Plate (Double Thoracic) ●Manufacturer no. RAT-4-4637 | 1 | Quote | Ask for a quote |
| 3 | Plate Cleat [Single] ● ● ●Manufacturer no. RAT-4-1031 | 1 | Quote | Ask for a quote |
| 4 | Freestander Plate Fitting [Single] ● ● ●Manufacturer no. RAT-4-1638 | 1 | Quote | Ask for a quote |
| 5 | Flexi Chest Laterals (Size 1) -MW ●Manufacturer no. LPS/1/103-XX | 1 | Quote | Ask for a quote |
| 5 | Flexi Chest Laterals (Size 2) -MB ●Manufacturer no. LPS/2/103-XX | 1 | Quote | Ask for a quote |
| 5 | Flexi Chest Laterals (Size 3) -MB ●Manufacturer no. LPS/3/103-XX | 1 | Quote | Ask for a quote |
| 5 | Flexi Chest Laterals (Size 3) (Double Thoracic) -MB ●Manufacturer no. LFS/3/103-XX | 1 | Quote | Ask for a quote |
| 6 | Chest Fitting [Single] ● ● ●Manufacturer no. 101-1963 | 1 | Quote | Ask for a quote |
Freestander Spare Parts - Hip Plate & Bands
8 partsExploded view from the manufacturer's parts manual (Freestander Parts Manual). The numbers on the drawing match that manual's parts list. Tell us the number and the model and our order desk will quote the part.
| No. | Part | Qty | Price | Action |
|---|---|---|---|---|
| 1 | Pelvic Band (Size 1) -MW ●Manufacturer no. LPS/1/B-XX | 1 | Quote | Ask for a quote |
| 1 | Pelvic Band (Size 2) -MB ●Manufacturer no. LPS/2/B-XX | 1 | Quote | Ask for a quote |
| 1 | Pelvic Band (Size 3) -MB ●Manufacturer no. LPS/3/B-XX | 1 | Quote | Ask for a quote |
| 2 | Hip Plate (Size 1) -MW ●Manufacturer no. LFS/1/L-XX | 1 | Quote | Ask for a quote |
| 2 | Hip Plate (Size 2) -MB ●Manufacturer no. LFS/2/L-XX | 1 | Quote | Ask for a quote |
| 2 | Hip Plate (Size 3) -MB ●Manufacturer no. LFS/3/L-XX | 1 | Quote | Ask for a quote |
| 3 | Freestander Plate Fitting [Single] ● ● ●Manufacturer no. RAT-4-1638 | 1 | Quote | Ask for a quote |
| 4 | Plate Cleat [Single] ● ● ●Manufacturer no. RAT-4-1032 | 1 | Quote | Ask for a quote |
Parts manuals for this model
The manufacturer parts lists and exploded diagrams we hold. If you can find the number on one of these, quote it to us and we will match it.
Not sure which part you need?
Send us a photo of the part, or of where it sits, and tell us what it is doing. Our order desk identifies parts for this equipment every day, and we would rather ask you one question than ship you the wrong bolt.
