Beka Carlo Alu Comfort Ep

The Beka CARLO Alu Comfort EP is Beka Hospitec's aluminum floor lift with a bathing hanger bar. Savaria Patient Care lists it for North America as Comfort EP 185 and Comfort EP 230. Westin Healthcare quotes it, delivers it, and sets it up for homes and care rooms in Brampton and the Greater Toronto Area.

Comfort EP is not the CARLO Classic we already sell. Classic (SKU 924003218, live at Beka CARLO Classic) uses a loop carry bar and has no Electrical Positioning System. Comfort EP uses a 4-point clip hanger bar with EPS, so the caregiver can move the person from sitting to lying from the hand control. If you were named the loop-bar Classic, stay on that page. If you were named Comfort EP, or you need the clip bathing bar, this is the listing.

Who it is for

This lift is for a person who needs a hospital-grade floor lift for bed, bath, shower, and toilet transfers, when the therapist has named a Beka CARLO Comfort EP and a clip comfort sling. If 185 kg is not enough, pick Comfort EP 230 (230 kg / 507 lb). If you need a loop sling on a CARLO, use the CARLO Classic. If you want a foldable home lift, see the Handicare Carina 350. Another Beka product we sell is the Beka Nora sit-to-stand lift, which is a different transfer type.

• Facilities and homes that asked for CARLO Comfort EP, not Classic
• Bathing and showering transfers on Beka's clip bathing hanger
• People inside 185 kg on Comfort EP 185, or 230 kg if you pick Comfort EP 230
• Lower beds, when you pick the 185 low-leg code

How it lifts

The caregiver opens the powered legs, seats a Beka clip comfort sling on the 4-point EP bar, and raises the boom from the hand control. EPS tilts the hanger so the person can go from sitting to lying (and back) without the caregiver forcing the bar. ARM limits unwanted swing. The bar has 360 degrees of free rotation and lowers to the floor for a floor pickup. Dual controls ship on the NA codes in this listing.

Beka prints an emergency stop, manual emergency lowering on the actuator, and electrical emergency lowering on the control box. Charge the removable 24 V battery about 4 hours before first use. On the Canadian control, charge only with the emergency stop released. Do not use the lift while it is charging. Beka's Comfort brochure says ARM allows a single caregiver transfer. That is Beka's ARM line, not a promise that every transfer is a one-person job. We will still assess the person and the room with you.

Beka CARLO Alu Comfort EP specifications

These figures are for Comfort EP, not Classic and not Carina 350. Savaria and Beka print 185 kg (408 lb) on Comfort EP 185 and 230 kg (507 lb) on Comfort EP 230. Neither is 500 lb. Comfort EP 185 is about 55 kg (121 lb). Comfort EP 230 is about 65 kg (143 lb). Lifting range is 1,400 mm (55.1 in) on both. Overall height is 1,340-2,170 mm (52.8-85.4 in). Castors are 100 mm (3.9 in) doubles, two with brakes. The drive is a 24 V LINAK unit. The battery is a removable 24 V lead-acid pack at 2.9 Ah. The lift is IPX4. The battery and wall charger are IPX5.

Comfort EP 185 chassis is 1,290 mm long and 125 mm high (50.8 in x 4.9 in). Inner base is 540-1,040 mm (21.3-40.9 in). Outer base is 700-1,180 mm (27.6-46.5 in). Comfort EP 230 chassis is 1,400 mm long and 125 mm high (55.1 in x 4.9 in). Inner base is 540-1,100 mm (21.3-43.3 in). Outer base is 700-1,240 mm (27.6-48.8 in). Comfort EP 185 is 100% aluminum. Comfort EP 230 is aluminum plus steel, with an extra-wide stainless steel 4-point bar. Do not read Classic loop-bar language onto this page. Do not read the 185 chassis onto a 230 quote.

Model options

Use the Model selector to pick the factory code on your quote:

• 925006008: Comfort EP 185, onboard charging and dual controls (185 kg / 408 lb)
• 925006018: Comfort EP 185, two batteries, wall charger, and dual controls (185 kg / 408 lb)
• 925006108: Comfort EP 185 with low legs, onboard charging and dual controls (185 kg / 408 lb)
• 925007008: Comfort EP 230, onboard charging and dual controls (230 kg / 507 lb)
• 925007018: Comfort EP 230, two batteries, wall charger, and dual controls (230 kg / 507 lb)

This listing is quote-only. The lift, clip EP hanger bar, hand control, and the charging kit on the code you pick come with the model. A sling is sold separately. Ask us for 925006108 if the bed is too low for the standard 185 legs. Low legs are a 185 option only. An optional calibrated scale is quoted with the room, not as a picker value.

Funding help for a patient lift in Ontario

Ontario's Assistive Devices Program (ADP) does not cover patient lifts or other lifting devices. Funding routes that can help when the eligibility criteria fit: ODSP, March of Dimes Canada, and hardship funding programs. Westin Healthcare's staff work with these programs every week and will point you to the right route for your situation. Visit our funding page or call (905) 451-7743 to talk it through before you buy.

Delivery and setup in Brampton and the GTA

Westin's own team delivers and sets up this lift across Brampton and the Greater Toronto Area. We bring it in, assemble it, and show you the hand control before we leave.

We have three stores in the Brampton and Toronto area if you would rather see a lift first. For a scheduled in-home setup, call (905) 451-7743 and we will book the next date that works. Same-day delivery is offered through our patient lift rental service; purchased lifts are delivered and set up on a scheduled date.

Floor patient lifts are oversized. The Canada-wide free ground-shipping offer on smaller goods does not apply. If the lift is going outside the GTA, ask us for a freight quote. Inside Toronto and the GTA, White-Glove Delivery (bring-in, unwrap, test, take packaging away) is described on the shipping policy. Any charge is confirmed on your order.

Can I rent a patient lift before I buy?

Yes. If you only need a lift for a recovery, or you want to live with a floor lift before you buy, rent first. See current packages and rates on the rentals hub and the patient lift rentals page. Westin rents electric floor lifts across Brampton and the GTA.

The rental fleet is typically a home-care electric lift, not this hospital-grade CARLO Comfort EP. For rentals we offer same-day delivery in Brampton, Etobicoke, Toronto, and Mississauga, and next-day delivery for other areas, with one day of notice.

If you later decide to buy, ask us about the Rental to Purchase First Month Credit program (an active Westin loyalty program). The rentals hub and rental program FAQs have the program rules.

Which slings this lift fits

Comfort EP uses a 4-point EP hanger bar for clip comfort slings only. Beka's IFU marks the Comfort attachment points "only for slings with clips" and warns against loop slings. That is the opposite of the CARLO Classic loop bar. The installed working load is the lowest rating among the lift, the bar, and the sling.

Beka names clip transfer slings, clip bathing slings (nylon mesh), clip toilet slings, and clip soft slings, in sizes with a headrest and padded leg support. We quote a Beka clip comfort sling with this lift. Sit-to-stand thorax slings belong on a sit-to-stand lift such as the Nora, not on this boom.

Westin's everyday sling shop is mostly loop styles: full-body slings, universal slings, and toileting slings. Those loop slings are for Classic and other loop bars, not for Comfort EP. Ask us for the clip sling that matches the model and the working load. A 185 kg sling is not enough on Comfort EP 230.

Service, repairs, and warranty

When something on the lift needs work, you call the shop that set it up, not a German parts desk. Westin Healthcare has a service and repairs department. Our technicians come to the home or workplace.

Beka manufacturer warranty

Beka and Savaria do not print a year split on the current Comfort EP cards we used. Ask us for the Beka terms that ship with your serial number. Authorized Beka service keeps that warranty in force. We handle the claim with you. Ask us if an extended warranty is offered for your order.

Frequently asked questions

Does funding cover a patient lift in Ontario?

Ontario's Assistive Devices Program (ADP) does not cover patient lifts. Other routes can help when the person and the assessment fit, including ODSP, March of Dimes Canada, and hardship programs. Westin Healthcare works with those programs every week. Call (905) 451-7743 or use the funding page before anyone starts paperwork.

What is the safe working load of the CARLO Alu Comfort EP?

Comfort EP 185 is 185 kg (408 lb). Comfort EP 230 is 230 kg (507 lb). The installed system is limited by the lowest rating among the lift, the hanger bar, and the sling. Stay inside that number for the person plus anything in the sling. Neither model is 500 lb.

How is Comfort EP different from the CARLO Classic we already sell?

Classic (live at /beka-carlo-lift/, SKU 924003218) is the loop-bar CARLO with no EPS. Comfort EP is the clip-bar CARLO with EPS and the bathing hanger. Same brand family, different attachment and a different job. If the prescription says loop slings, stay with Classic. If it says Comfort EP or clip comfort slings, use this page.

What slings fit Comfort EP?

Beka clip comfort slings on the 4-point EP bar. Transfer, bathing, toilet, and soft clip slings are the families Beka names. Loop slings belong on Classic. We will quote a clip sling that matches the 185 kg or 230 kg model you pick.

Does a sling come with the lift?

No. Beka ships the lift with the clip EP hanger bar, the hand control, dual controls, and the charging kit on the code you pick. The sling is sold separately. We will confirm the size and the working load when we book setup.

What is EPS on this lift?

Electrical Positioning System. The hand control tilts the hanger so the caregiver can move the person from sitting to lying, or the other way, without forcing the bar by hand. Beka names that for bed and toilet positioning. Classic does not have EPS.

Can one caregiver operate the Comfort EP?

Beka's Comfort brochure says ARM allows a single caregiver transfer. Other transfers still need an assessment. We will not promise that one person is always enough.

Does Comfort EP fold for a car or a closet?

No. This is a hospital-grade frame that stays assembled. For a compact Handicare fold, see the Carina 350.

Can I rent a Comfort EP before buying?

The rental page is usually a home-care electric lift. Call (905) 451-7743 if you want to try a floor lift before you commit to this hospital-grade clip frame.

How fast can a purchased Comfort EP be set up in the GTA?

Westin's team delivers and sets up purchased lifts across Brampton and the GTA on a scheduled date. Call (905) 451-7743 for the next opening. Same-day delivery belongs to the rental service, not automatically to a purchased setup.

What is included with code 925006008?

You get Comfort EP 185 with the clip EP hanger bar, onboard charging, and dual controls. Use Model if you need two batteries and a wall charger, low legs, or Comfort EP 230. A sling is not included. Westin Healthcare delivers and sets up across Brampton and the GTA.

What is the warranty on the Comfort EP?

Ask us for the Beka terms that ship with your serial number. Authorized Beka service keeps that warranty in force. Westin Healthcare processes the warranty work. Details are on our service and repairs page.
