Drive 30" Bariatric Sentra EC Heavy-Duty, Extra-Extra-Wide Wheelchair - STD30ECDDA

The Drive 30" Bariatric Sentra EC is Drive Medical's extra-wide Sentra EC chair, sold here as STD30ECDDA (desk arms) or STD30ECDFA (full arms). Westin Healthcare sells it and delivers it for homes in Brampton and the Greater Toronto Area. It is the 30 inch member of Drive's 26 / 28 / 30 inch extra-wide set. The default chair is the desk-arm SKU STD30ECDDA.

Drive lists a 30 inch by 20 inch seat, a 66 lb chair, a 700 lb weight capacity, and flat-free 8 inch front casters. Rear wheels are steel spoke so the person can self-propel. Dual cross bars and steel gussets carry the extra width and the 700 lb rating.

Who this chair is for

This chair is for a person who needs a 30 inch self-propel seat and a Drive 700 lb rating. Families usually call us when a 28 inch extra-wide seat is still too narrow.

If 28 inches is enough, start with the Drive 28 inch Sentra EC. The 26 inch chair is the Drive 26 inch Sentra EC. If a caregiver will push and the person does not need to self-propel, see the Drive 22 inch BTR22.

• Self-propel use on steel spoke rear wheels
• A Drive 700 lb rating on a reinforced chrome-finished frame
• A 30 inch by 20 inch seat

Design and build

The frame is carbon steel with a triple-coated chrome finish. Drive reinforces the weight-bearing points with steel gussets, and it uses dual cross bars, a reinforced side frame, and extra-heavy-duty front forks. Upholstery is reinforced nylon. Armrests are extra-large and padded.

Rear wheels are steel spoke. Front casters are heavy-duty flat-free 8 inch, adjustable in two positions. Push-to-lock wheel locks hold the chair for sitting and standing. Drive lists swing-away footrests as PH-SF and elevating leg rests as PHELR, each with extra-large aluminum foot plates. Ask us to include the rigging you need on the order.

The chair folds. Drive lists 39 inches open and 15 inches closed for this 30 inch SKU. Drive's owner manual says the chair is not a car seat.

Drive 30" Bariatric Sentra EC specifications

These figures are for Westin SKU STD30ECDDA, with STD30ECDFA as the full-arm option. The specification tab holds the stored values. Drive's current 30 inch extra-wide table lists a 30 inch by 20 inch seat, a 66 lb chair, a 72 lb carton, a 700 lb capacity, a 19.5 inch seat-to-floor height, an 18 inch back, 39 inches open, and 15 inches closed. Length with riggings is 43 inches. Height is 35 inches.

Do not mix these numbers with the 26 or 28 inch Sentra EC chairs, or with the Sentra Extra Heavy Duty 20-24 inch line. Those Extra HD chairs are 500 lb with an 18 inch seat depth.

Warranty for the original purchaser is Drive's Lifetime Limited term: defects in materials and workmanship for the life of that purchaser. It does not cover misuse, negligence, or normal wear, and it does not extend to rubber accessories, casters, and grips.

Arm options

Use Choose Armrests to set desk-length or full-length pads. Drive's 30 inch arm SKUs are:

Choose Armrests

• Desk arm pads (STD30ECDDA)
• Full arm pads (STD30ECDFA)

Both arms are extra-large and padded. The default chair is STD30ECDDA. Tell us if you need swing-away footrests (Drive PH-SF) or elevating leg rests (Drive PHELR) on the chair.

Funding help for a bariatric wheelchair in Ontario

Ontario's Assistive Devices Program (ADP) can fund 75% of the cost of a manual wheelchair when the need is long-term and the chair is prescribed through an assessment by an ADP-registered occupational therapist or physiotherapist, and some income-support programs cover the full cost. Not every chair qualifies, so talk to us before you buy. March of Dimes Canada, Veterans Affairs Canada (VAC), and community programs can also help. Westin Healthcare's staff work with these programs every week and will point you to the right route for your situation. Visit our funding page or call (905) 451-7743 to talk it through.

Delivery and setup in Brampton and the GTA

Westin's own team delivers this wheelchair across Brampton and the Greater Toronto Area. We bring it in, unfold it, set the footrests, and show you the wheel locks and the fold before we leave.

We have three stores in the Brampton and Toronto area if you would rather see a chair first. For a scheduled delivery, call (905) 451-7743 and we will book the next date that works. Same-day delivery is offered through our hospital bed rental service; purchased chairs are delivered on a scheduled date.

This chair folds. It is still a 66 lb extra-wide steel chair, so plan the path through the home before delivery day. If it is going outside the GTA, ask us for a shipping quote. Inside Toronto and the GTA, White-Glove Delivery (bring-in, unwrap, test, take packaging away) is described on the shipping policy. Any charge is confirmed on your order.

Related mobility products from Westin

• Drive 28" Bariatric Sentra EC, the narrower chair in this extra-wide set
• Drive 26" Bariatric Sentra EC, the 26 inch extra-wide sibling
• Drive 22" Bariatric Steel Transport Chair BTR22, a companion-push chair if self-propel is not needed

Service and warranty

When something on the chair needs work, you call the shop that sold it, not a US parts desk. Westin Healthcare has a service and repairs department. Our technicians come to the home or workplace.

Drive manufacturer warranty

Drive's owner manual for the Sentra extra-wide family prints a Lifetime Limited Warranty for the original purchaser: free of defects in materials and workmanship for the lifetime of that purchaser. The warranty does not cover misuse, negligence, or normal wear, and it does not extend to non-durable parts such as rubber accessories, casters, and grips. We handle the warranty claim with you. Ask us if an extended warranty is offered for your order.

Frequently asked questions

What is the difference between this wheelchair and a transport chair?

This Sentra EC has large steel spoke rear wheels so the person can push themselves. A transport chair has small rear wheels and is built for a caregiver to push. BTR22 is the companion-push sibling if that is the better fit.

Who pushes the 30 inch Sentra EC?

The person in the chair can self-propel. A companion can also push from the rear handgrips. Wheel locks are push-to-lock. Drive's owner manual asks for care on ramps and says the chair is not a car seat.

Will it fold into a car trunk?

Drive lists 15 inches closed and 43 inches long with the riggings. The frame folds. At 66 lb it is a two-person lift for most trunks. It is not approved as a seat inside a moving vehicle.

How do I measure for a 30 inch seat?

Measure the seated hip width and leave a little room on each side. This seat is 30 inches by 20 inches. If 28 inches is enough, use the 28 inch Sentra EC.

Will a 30 inch chair fit through the doorway?

Measure the clear opening, not the door slab. Drive lists 39 inches overall for this 30 inch SKU. Most interior doors are narrower than that. Plan the route through the home, or see the chair in the store, before you order.

What is the weight capacity?

Drive lists 700 lbs for STD30ECDDA and STD30ECDFA. The 26 and 28 inch extra-wide chairs share that 700 lb rating. The Extra HD 20-24 inch chairs are a different line at 500 lb.

Why 8 inch flat-free front casters?

Drive fits heavy-duty flat-free 8 inch casters so the front does not go flat under a 700 lb rating. They adjust in two positions. Rear wheels stay steel spoke for self-propel.

What is the warranty?

Drive's sheet and owner manual print a Lifetime Limited term for the original purchaser. Wear items such as casters and grips are outside that term. Westin Healthcare processes the claim.

Can funding help with this chair in Ontario?

Some Ontario routes can help with mobility equipment. Eligibility depends on the person's situation and assessment. Call (905) 451-7743 or use the funding page before you buy.

Can I rent a bariatric wheelchair before I buy?

Westin Healthcare rents some mobility equipment. Ask us whether a bariatric wheelchair can go out as a rental for your dates. Purchased chairs are delivered on a scheduled date.

Do footrests come on the chair?

Drive lists swing-away footrests as PH-SF and elevating leg rests as PHELR and sells them as separate items. Tell us which pair you need when you order. Use Choose Armrests only for desk or full pads.
