Description
The Pride Jazzy Carbon 27 is Pride Mobility's JAZZY CARBON 27 folding power wheelchair. Westin Healthcare sells it and delivers it for homes in Brampton and the Greater Toronto Area. It is a carbon fibre travel chair that folds in one piece. The person drives with the joystick.
Pride lists a 300 lb (136 kg) rating, speeds up to 3.7 mph (6.0 km/h), a 33.4 inch turning radius, and up to 9.3 miles (15.0 km) per charge on the 12 Ah lithium pack. The chair weighs 27.8 lbs without the battery. Pride weighs that pack at 4.6 lbs.
Who this chair is for
This chair is for a person who fits Pride's 17 by 17 inch seat, stays at or under the 300 lb rating, and wants a folder one person can lift into a trunk. Families usually call us when the original Jazzy Carbon's 39 lb frame is more lift than they want, or when they want the newer LCD joystick with a USB-C port.
If you want an 18 by 18 inch sling that folds upright like a manual chair, start with the Pride Jazzy Carbon 27X. If you need a 400 lb rating and a 20 by 20 inch seat, see the Pride Jazzy Carbon HD. The Carbon 27 is not a take-apart Go Chair.
- A 27.8 lb carbon fibre fold, without the battery
- A 17 by 17 inch mesh-back seat
- A 12 Ah lithium pack Pride describes as airline-compliant, with the airline still to confirm
Range, speed, and batteries
The Pride Jazzy Carbon 27 travels up to 9.3 miles (15.0 km) per charge on the standard 12 Ah lithium box. Pride's footnotes say range changes with user weight, terrain, battery charge, battery condition, and tire condition, and that the number can move 10 percent either way. Plan a shorter day than 15 km if the person is near 300 lbs or the route is not flat.
Top speed is up to 3.7 mph (6.0 km/h). The charger is a 2-amp off-board unit. Charge the pack with the charger Pride supplies. Pride catalogs a second 12 Ah airline-compliant pack as an add-on. Pride's brochure still marks an extra 20 Ah pack as coming soon, so ask us what we can order today.
Portability and transport
Pride folds the Carbon 27 as one piece and secures it with a strap. Folded size on the brochure is 27.5 inches long, 23.4 inches wide, and 13.38 inches high. It does not come apart into a stack of frame pieces. The joystick disconnects for the trip.
Pride prints the 12 Ah lithium pack as airline-compliant and still says transport on a commercial aircraft is subject to federal regulations and airline policy. Consult the airline before you fly. Pride does not print a watt-hour figure on this chair's spec table, so we do not invent one. For a cruise or a bus, ask the carrier what they allow on board.
Pride Jazzy Carbon 27 specifications
These figures are for Pride model JAZZY CARBON 27, as printed on Pride's specification table, the 061626 brochure, and the Pride Canada card. The specification tab holds the stored values.
Weight capacity 300 lbs (136 kg). Top speed up to 3.7 mph (6.0 km/h). Turning radius 33.4 inches. Length 35.04 inches. Width 23.43 inches. Ground clearance 1 inch at the motor. Front wheels 6.89 inches. Rear wheels 8.27 inches. Full front suspension. Motors 24V 250W brushless. Brakes regenerative and electromechanical.
Seat 17 by 17 inches, mesh back, solid seat pan, removable cushion. Flip-up carbon fibre arms. LCD joystick with digital display, USB-C port, and puddle light. Mesh cup holder, adjustable lap belt, and under-seat storage are standard. Colours Pride sells are Black Cherry and Night Sky.
Do not mix these numbers with the original Jazzy Carbon (39 lbs, 24 inch turn, 288Wh pack) or with the Carbon 27X.
Warranty on Pride's US brochure is 5 years on the frame and 1-year limited on electronics, drivetrain, and battery. Pride Canada's card prints a lifetime limited term on the frame and 1-year limited terms on electronics, drive motors, and batteries. Ask us which insert ships with your chair.
Jazzy Carbon 27 or Jazzy Carbon 27X
The Carbon 27 is Pride's 300 lb, 17 by 17 inch strap-fold chair with a 12 Ah pack and a 33.4 inch turn. The Carbon 27X is Pride's 275 lb, 18 by 18 inch X-frame chair that folds vertically to 12 inches wide, with a 10 Ah pack. They are separate Pride models. If you want the older 39 lb Jazzy Carbon, that page is still Jazzy Carbon.
Funding help for a power wheelchair in Ontario
Ontario's Assistive Devices Program (ADP) can fund 75% of the cost of a power wheelchair when the need is long-term and the chair is prescribed through an assessment by an ADP-registered occupational therapist or physiotherapist, and some income-support programs cover the full cost. Not every chair qualifies, so talk to us before you buy. March of Dimes Canada, Veterans Affairs Canada (VAC), and community programs can also help. Westin Healthcare's staff work with these programs every week and will point you to the right route for your situation. Visit our funding page or call (905) 451-7743 to talk it through.
Delivery and setup in Brampton and the GTA
Westin's own team delivers and sets up this power wheelchair across Brampton and the Greater Toronto Area. We bring it in, unfold it, and show you the joystick, the fold strap, and the charger before we leave.
We have three stores in the Brampton and Toronto area if you would rather see a chair first. For a scheduled in-home setup, call (905) 451-7743 and we will book the next date that works. Same-day delivery is offered through our hospital bed rental service; purchased chairs are delivered and set up on a scheduled date.
This power wheelchair folds for a car trunk. If it is going outside the GTA, ask us for a freight quote. Inside Toronto and the GTA, White-Glove Delivery (bring-in, unwrap, test, take packaging away) is described on the shipping policy. Any charge is confirmed on your order.
Related mobility products from Westin
- Pride Jazzy Carbon 27X, the X-frame vertical folder
- Pride Jazzy Carbon HD, the 400 lb carbon folder
- Pride Jazzy Carbon, the original 39 lb Jazzy Carbon
Service and warranty
When something on the chair needs work, you call the shop that set it up, not a US parts desk. Westin Healthcare has a service and repairs department. Our technicians come to the home or workplace.
Pride manufacturer warranty
Pride's Carbon 27 US brochure prints 5 years on the frame and 1-year limited terms on electronics, drivetrain, and battery for the original purchaser. Pride Canada's card prints a lifetime limited term on the frame and 1-year limited terms on electronics, drive motors, and batteries. Wear items such as tires, upholstery, and shrouds sit outside that term. Gradual battery wear from storage, cold, or heavy use is outside the battery term. We handle the warranty claim with you. Ask us if an extended warranty is offered for your order.
Frequently asked questions
How Much Does The Jazzy Carbon 27 Weigh?
The Pride Jazzy Carbon 27 weighs 27.8 lbs without the battery. Pride lists the 12 Ah pack at 4.6 lbs, for about 32.4 lbs with the battery on (Pride Canada's table prints 32.38 lbs).
How Far Will The Jazzy Carbon 27 Go On One Charge?
The Pride Jazzy Carbon 27 travels up to 9.3 miles (15.0 km) per charge on the 12 Ah lithium pack. Pride's footnotes say range changes with weight, terrain, and battery condition.
Is The Jazzy Carbon 27 Airline Approved?
Pride prints the Jazzy Carbon 27's 12 Ah lithium pack as airline-compliant and still says you must consult the airline before the flight. Transport on a commercial aircraft is subject to federal regulations and airline policy.
Does The Jazzy Carbon 27 Fold Or Come Apart?
The Pride Jazzy Carbon 27 folds as one piece and secures with a strap. Pride's folded size is 27.5 by 23.4 by 13.38 inches. It does not take apart like a Go Chair.
What Seat Size Does The Carbon 27 Use?
The Pride Jazzy Carbon 27 uses a 17 by 17 inch seat with a mesh back, a solid seat pan, and a removable cushion. Pride does not print a larger factory seat on this model.
What Is The Weight Capacity?
The Pride Jazzy Carbon 27 is rated at 300 lbs (136 kg). Stay at or under that rating.
What Colours Can I Order?
Pride sells the Jazzy Carbon 27 in Black Cherry and Night Sky. Ask us which colour we can put on your order.
How Is This Different From The Original Jazzy Carbon?
The Pride Jazzy Carbon 27 is the newer 27.8 lb chair with a 33.4 inch turn and a 12 Ah pack. The original Jazzy Carbon is the 39 lb chair with a 24 inch turn and a 24V 12Ah (288Wh) pack. They are separate Pride models.
What Is The Warranty?
Pride's US Carbon 27 brochure prints 5 years on the frame and 1 year on electronics, drivetrain, and battery. Pride Canada's card prints a lifetime limited frame term and 1-year limited electronics, motors, and batteries. Westin Healthcare processes the claim.
Can Funding Help With This Chair In Ontario?
Some Ontario routes can help with mobility equipment. Eligibility depends on the person's situation and assessment. Call (905) 451-7743 or use the funding page before you buy.
Can I Rent A Power Wheelchair Before I Buy?
Westin Healthcare rents some power wheelchairs. The live rental page is a different chair. Ask us whether a Carbon 27 can go out as a rental for your dates. Purchased chairs are delivered on a scheduled date.
Specifications
| Colors | Black Cherry, Night Sky |
|---|---|
| Brands | Pride |
| Warranty | US brochure 5-yr frame / 1-yr electronics, drivetrain, battery; CA card lifetime frame / 1-yr electronics |
| Weight Capacity | 300 lbs (136 kg) |
| Caster Size | 6.89" front |
| Compatible Batteries | Lithium battery box, 12 Ah, 4.6 lbs |
| Drive Terrain Type | 24V 250W brushless motors |
| Driving Range | Up to 9.3 miles (15.0 km) per charge |
| Foldable | Yes (one-piece fold with strap; does not disassemble) |
| Ground Clearance | 1" at motor |
| Product Weight | 27.8 lbs without battery; 4.6 lb 12 Ah pack; about 32.4 lbs with battery |
| Top Speed | Up to 3.7 mph (6.0 km/h) |
| Turning Radius | 33.4" |
| Wheel Size | 8.27" rear |
| Wheelchair Type | Folding travel power wheelchair |
| Overall Length | 35.04" |
| Overall Width | 23.43" |
| Battery Charger | 2-amp off-board |
| Drivetrain | 24V 250W brushless |
