Description
The Span America Gel-T is a 2.5 inch gel-and-foam wheelchair seat cushion. Span America is a Savaria company. Westin Healthcare quotes it and delivers it for homes and care sites in Brampton and the Greater Toronto Area.
This page is the Gel-T seat cushion only. Span places a segmented gel-filled bladder between two soft foam layers so the gel stays under the bony points that need it. The 2.5 inch height is a lower profile than the Geo-Matt PRT foam cushion. Span writes it for comfort, for prevention of breakdown, and for people at moderate risk of pressure injuries. If a clinician has named the Geo-Matt PRT, the Geo-Matt cushion, Geo-Matt Contour, Geo-Matt Wedge, Geo-Wave, or The Equalizer, ask us for that product. Those are separate Span articles.
Who this cushion is for
This cushion is for a wheelchair or geri-chair user who needs a wipeable, non-powered gel-and-foam seat and whose weight is within Span's rating for the size you pick. Span writes it for people at moderate risk of pressure injuries who want immersion from gel without a pump.
Families and therapists usually call us when the person already uses a wheelchair or a geri-chair and the seating plan asks for Gel-T, not a foam Geo-Matt and not a mattress pad. If the care team has asked for an in-bed Span surface, we already stock PressureGuard Custom Care and Span-Care mattresses and will quote those separately.
- Wheelchair seats 15, 16, 17, or 18 inches wide
- Geri-chair seats 19, 20, or 21 inches wide, on the sizes Span prints as geri-chair fits
- Wider bariatric seats 22 or 24 inches on the B8022 and B8024 sizes
Construction and how it works
The Gel-T is a non-powered seat cushion. Span cradles a segmented gel-filled bladder between two soft foam layers. The segments hold the gel under the bony points instead of letting it slide away. The foam on top and bottom gives a conforming surface and keeps the bladder in place. Span writes that this stack maximises immersion and reduces pressure and pain.
The cover is wipe-clean vinyl with a non-skid bottom. It keeps moisture out and helps reduce shear and friction. The cover can take Span's optional Sling-Fill base when the chair has a fabric sling seat. That insert is sold separately. It fills the hammock in a fabric sling and gives the cushion a flat, rigid foundation.
Span America Gel-T specifications
These figures are for the Gel-T in the 801x-05 and B802x-05 codes on this page. They are not the Geo-Matt PRT sheet and not The Equalizer sheet. The specification tab holds the stored values.
Span lists a 2.5 inch height. Weight limit is 250 lb on sizes through 18 by 16 inches, 350 lb on 18 by 18 inches and larger, and 500 lb on the 22 and 24 inch bariatric sizes. The cushion is non-powered. Span lists an 18-month warranty. Fire-barrier versions are ordered by changing the -05 suffix to -29.
Size options
Use Choose Cushion Size. Match the cushion width to the wheelchair or geri-chair seat width. The default on this page is 18 in W x 16 in L x 2.5 in H (801816-05).
- 15 in W x 15 in L x 2.5 in H (8015-05)
- 16 in W x 16 in L x 2.5 in H (8016-05)
- 16 in W x 18 in L x 2.5 in H (801618-05)
- 17 in W x 17 in L x 2.5 in H (8017-05)
- 18 in W x 16 in L x 2.5 in H (801816-05)
- 18 in W x 18 in L x 2.5 in H (8018-05)
- 19 in W x 19 in L x 2.5 in H, geri-chair (8019-05)
- 20 in W x 18 in L x 2.5 in H, geri-chair (802018-05)
- 21 in W x 21 in L x 2.5 in H, geri-chair (8021-05)
- 22 in W x 18 in L x 2.5 in H, bariatric (B802218-05)
- 24 in W x 18 in L x 2.5 in H, bariatric (B802418-05)
Fire-barrier -29 covers and the Sling-Fill insert are quoted with the room. Ask us if the seating plan names those options.
Delivery in Brampton and the GTA
Westin's own team can deliver this cushion across Brampton and the Greater Toronto Area, on its own or with a bed or lift setup. We have three stores in the Brampton and Toronto area if you would rather see a cushion first. For a scheduled drop-off, call (905) 451-7743 and we will book the next date that works.
This is a small carton. The Canada-wide free ground-shipping offer on smaller goods can apply when it ships without a bed or a lift. If it travels with a hospital bed, the bed is oversized and White-Glove Delivery is described on the shipping policy. Any charge is confirmed on your order.
Which wheelchairs this cushion fits
Span publishes the Gel-T in wheelchair and geri-chair seat widths of 15, 16, 17, 18, 19, 20, 21, 22, and 24 inches. Choose the width that matches the seat sling or seat pan. Span does not name a wheelchair brand or model. Tell us the measured seat width and depth and we will lock the matching code.
For a typical adult wheelchair, start with 18 by 16 inches (801816-05) or 16 by 16 inches (8016-05). Use 16 by 18 inches (801618-05) when the seat is 16 inches wide and 18 inches deep. Span prints 19 by 19 inches (8019-05), 20 by 18 inches (802018-05), and 21 by 21 inches (8021-05) as sizes that fit geri-chairs. The 22 by 18 and 24 by 18 inch sizes are the bariatric pair.
The cover can take Span's molded Sling-Fill base. Span writes that the insert fills the gap created by a fabric sling and creates a flat, rigid foundation. The insert is one size and is not included with the cushion. Ask us to add Sling-Fill (2SFB) to the quote when the chair has a hammocked sling seat.
If the person also needs help standing from the chair, we already sell the Handicare ReTurn. If the room also needs a Span sleep surface, see the Span America Advantage and ask us for the PressureGuard Custom Care or Span-Care mattress we already stock. Browse gel cushions, hospital beds, and medical mattresses when the seating plan is only part of the room.
Service and warranty
When something on the cushion needs work, you call the shop that sold it. Westin Healthcare has a service and repairs department.
Span America manufacturer warranty
Span lists an 18-month warranty on the Gel-T. We handle the warranty claim with you. Ask us if an extended warranty is offered for your order.
Frequently asked questions
What is the Gel-T?
It is Span America's 2.5 inch gel-and-foam wheelchair seat cushion. A segmented gel-filled bladder sits between two soft foam layers. Span writes it for comfort, prevention of breakdown, and people at moderate risk of pressure injuries.
Is this a mattress overlay?
No. The Gel-T is a seat cushion for a wheelchair or a geri-chair. If the clinician named a Span mattress or overlay, ask us for that product.
How is Gel-T different from the Geo-Matt PRT?
Gel-T is gel and foam at 2.5 inches. Geo-Matt PRT is high-density segmented foam at 3 inches (4 inches on bariatric sizes). They do not share part numbers. Ask us for PRT if the seating plan named foam, not gel.
How is Gel-T different from The Equalizer and Geo-Wave?
The Equalizer is a taller multi-layer seating cushion with positioning features. Geo-Wave is a long wave-foam cushion built for a geri-chair seat and back. Gel-T is the lower, flat gel-and-foam seat. This page sells Gel-T only.
Does this cushion need a pump?
No. The Gel-T is non-powered gel and foam. There is no pump to plug in.
What is the weight rating?
Span lists 250 lb on sizes through 18 by 16 inches, 350 lb on 18 by 18 inches and larger, and 500 lb on the 22 and 24 inch bariatric sizes. Tell us the person's weight when you order.
What sizes can I get?
Standard: 15 by 15, 16 by 16, 16 by 18, 17 by 17, 18 by 16, and 18 by 18 inches. Geri-chair: 19 by 19, 20 by 18, and 21 by 21 inches. Bariatric: 22 by 18 and 24 by 18 inches. All are 2.5 inches high. The default on this page is 18 by 16 inches (801816-05).
Which wheelchair does it fit?
Match the cushion width to the wheelchair or geri-chair seat width. Span publishes those nine widths and does not name a chair brand. Measure the seat width and depth and we will pick the code.
Does Gel-T fit a geri-chair?
Span prints 19 by 19, 20 by 18, and 21 by 21 inches as sizes that fit geri-chairs. Measure the geri-chair seat before you pick. Geo-Wave is a different Span article if the plan named a long wave cushion instead.
Can I add a Sling-Fill base?
Yes. The cover can take Span's molded Sling-Fill insert (2SFB). Span sells the insert separately. Ask us to add it when the wheelchair seat is a fabric sling that hammocks.
How do I clean the cover?
Span specifies a wipe-clean vinyl cover with a non-skid bottom. Wipe it with the disinfectant your clinician allows.
What is the warranty?
Span lists an 18-month warranty on the Gel-T. Westin Healthcare processes the warranty work on our service and repairs page.
What is included?
You get the Span America Gel-T in the size you pick, with the vinyl cover on it. The wheelchair, the Sling-Fill insert, and any bed or mattress are sold separately.
Specifications
| Height | 2.5 in |
|---|---|
| Model | Gel-T gel-and-foam seat cushion (not Geo-Matt PRT, Contour, Wedge, Geo-Wave, or Equalizer) |
| Brands | Span America |
| Warranty | 18 Months |
| Weight Capacity | 250 lb on sizes through 18x16 in; 350 lb on 18x18 in and larger; 500 lb on bariatric 22x18 and 24x18 |
| Construction | Segmented gel-filled bladder between two soft foam layers |
| Standard Sizes | 15x15, 16x16, 16x18, 17x17, 18x16, 18x18 in |
| Cover | Wipe-clean vinyl cover with non-skid bottom |
| Therapy Class | Non-powered gel-and-foam wheelchair seat cushion |
| Intended Use | Comfort and prevention of breakdown; moderate risk of pressure injuries |
| Power | None. Non-powered. |
| HCPCS (US) | E2601; E2602 for 22 in or wider |
| Bariatric Sizes | 22x18, 24x18 in |
| Geri-chair Sizes | 19x19, 20x18, 21x21 in (Span: fits geri-chairs) |
| Sling-Fill | Optional Sling-Fill base (2SFB), not included |
| Fire Option | Replace -05 suffix with -29 for NFPA 101 and Cal TB 133 |
