Description
Span America Span+Aids Surgical and Post-Operative Positioners are body-site specific foam shapes for the operating room and the recovery bed. Span America is a Savaria company. Westin Healthcare quotes the family and delivers it for homes and care sites in Brampton and the Greater Toronto Area.
This page is the surgical and post-operative family, including the abduction pillows. Span+Aids were developed in conjunction with nurses, therapists, and surgeons to ensure that each product is effective for the need. If the care plan names Extremities positioners, Head and Body positioners, or Heel Manager, ask us for that listing. Those are separate Span+Aids articles.
Who these positioners are for
These positioners are for a surgical team, a recovery unit, or a home that needs a named Span+Aids foam shape after hip, knee, chest, or spine work. They are non-powered. They sit on the bed, the O.R. table, or the armboard named on that code.
Families and unit buyers usually call us when the order names an abduction pillow after hip surgery, a total-knee elevator, or an O.R. kit. If the person also needs a Span sleep surface we already stock, we will quote that bed or mattress on the same visit.
- Post-operative abduction after hip work, sized by height
- Named O.R. shapes for the head, arm, elbow, heel, sacrum, or axilla
- No pump to plug in
Construction and how they work
Each code is a cut foam positioner for one site. Selected codes are vacuum packed to save storage. All items on this family conform to California Technical Bulletin 117.
Abduction pillows use adjustable Velfoam straps. Comfort-band codes add a cotton comfort band. Contour codes add contoured leg channels. The Open Heart Surgery Kit holds each leg in externally rotated position for vein presentation. Special cuts allow for drainage tubes and sensors. Each kit includes 2 leg positioners, 2 heel protectors and 2 leg toppers.
The Heel Protector on this page provides comfort and protection. The adjustable strap allows a custom fit. Heel Manager is a separate dual-leg offloading elevator. The O.R. Table Pillow uses segmented squares for the head during surgery. Head Support and the O.R. Head Positioner sit on the Head and Body listing.
Span America Span+Aids Surgical and Post-Operative specifications
These figures are for the surgical and post-operative codes on this page. They are not Extremities limb elevators, not Head and Body wedges, and not Heel Manager. The specification tab holds the stored values.
The default code is the Standard Abduction Pillow, Medium (50642-540), 22 x 14 x 4 x 7 in. Span's height guide is: less than 5 ft tall use SML, 5 ft 1 in to 5 ft 11 in use MED, 6 ft to 6 ft 5 in use LRG. The Ulnar Nerve Protector is a full six inches wide. Foam positioning rings are offered in 7 in, 8 in, and 9 in diameters. Ask us for the current Span America warranty on the code you pick.
Positioner options
Use Choose Positioner. The default on this page is Standard Abduction Pillow, Medium (50642-540). Many O.R. codes ship by the case. The quote confirms the case count.
- Standard Abduction Pillow, Small, Medium, or Large
- Abduction Pillow with Comfort Band, Small, Medium, or Large
- Abduction Pillow with Contour and Comfort Band, including Wide
- Abduction Pillow with Contour, Small, Medium, or Large
- Open Heart Surgery Kit, Total Knee Leg Elevator, and 90 Degree Leg Elevator
- O.R. Table Pillow, Axilla Cuff, Thoracotomy Arm Sling, and Laminectomy Arm Cradle Set
- Elbow Protector, Heel Protector, Ulnar Nerve Protector, Sacral Pad, foam rings, and O.R. Armboard Pads
If the clinician named the Schaeffer Abduction Pillow with cradle boots, ask us to confirm that code on the quote. Economy case packs and Open Heart replacement toppers are quoted with the room.
Delivery in Brampton and the GTA
Westin's own team can deliver these positioners across Brampton and the Greater Toronto Area, on their own or with a bed or lift setup. We have three stores in the Brampton and Toronto area if you would rather see a sample first. For a scheduled drop-off, call (905) 451-7743 and we will book the next date that works.
Most codes ship in a small carton. The Canada-wide free ground-shipping offer on smaller goods can apply when they ship without a bed or a lift. If they travel with a hospital bed, the bed is oversized and White-Glove Delivery is described on the shipping policy. Any charge is confirmed on your order.
Which beds and rooms these positioners fit
Span does not name a bed brand for this family. The abduction pillows sit between the legs on the sleep surface. O.R. Armboard Pads are used on O.R. table armboards. The Thoracotomy Arm Sling is used with an ether screen bar. Tell us the procedure and the bed width and we will lock the matching code.
If the recovery room also needs a Span bed, see the Span America Encore and the Span America Advantage. If the person needs help standing after hip or knee work, we already sell the Handicare ReTurn. For a foam hospital mattress we already sell, see the Gravity 7. Ask us for the PressureGuard Custom Care or Span-Care mattress we already stock. Browse hospital beds and medical mattresses when the positioner is only part of the room.
Service and warranty
When something on the positioner needs work, you call the shop that sold it. Westin Healthcare has a service and repairs department.
Span America manufacturer warranty
Ask us for the current Span America warranty on the code you pick. We handle the warranty claim with you. Ask us if an extended warranty is offered for your order.
Frequently asked questions
What is the Span+Aids Surgical and Post-Operative family?
It is Span America's line of foam positioners cut for named surgical and post-operative sites. The family includes abduction pillows, O.R. head and arm shapes, elbow and heel wraps, sacral pads, and the Open Heart Surgery Kit.
How is this different from Span+Aids Extremities?
Extremities is the ward and long-term care limb family: Cradle Boot, Foot Drop Stop, Limb Elevator, Leg Trough, and the cock-up splint. This page is the surgical and post-operative set, including abduction pillows and O.R. kits. Ask us for Extremities when that is the article the clinician named.
How is this different from Head and Body positioners?
Head and Body holds the Geo-Matt Pillow, Head Support, the O.R. Head Positioner, positioning rolls, and the 30 degree and 45 degree body wedges. This page's O.R. Table Pillow is the segmented-square surgical head pillow. Ask us for Head and Body when the plan names a wedge or a Geo-Matt pillow.
How is the Heel Protector different from Heel Manager?
The Heel Protector on this page is a foam wrap with an adjustable strap. Heel Manager is a separate dual-leg offloading elevator with a wipe-clean cover. Ask us for Heel Manager when the order names that elevator.
What size abduction pillow do I need?
Span's guide is: less than 5 ft tall use Small, 5 ft 1 in to 5 ft 11 in use Medium, and 6 ft to 6 ft 5 in use Large. The default on this page is Medium (50642-540).
What is in the Open Heart Surgery Kit?
Each kit includes 2 leg positioners, 2 heel protectors and 2 leg toppers. It holds each leg in externally rotated position for vein presentation. Special cuts allow for drainage tubes and sensors. The code is 50666-525.
Does any code on this page need a pump?
No. Every shape on this page is non-powered foam. There is no pump to plug in.
Can I use these on a hospital bed at home?
Yes. Abduction pillows sit on the sleep surface. We already sell the Span America Encore and the Span America Advantage if the room also needs a Span bed. Measure the person and we will pick the abduction size.
What is the Total Knee Leg Elevator?
It is used in knee replacement surgery and elevates the leg in a flexed position. The 90 Degree Leg Elevator bends the knee at a 90 degree angle for surgery or physical therapy. Both are on the picker.
What is the warranty?
Ask us for the current Span America term on the code you pick. Westin Healthcare processes the warranty work.
What is included?
You get the Span+Aids positioner in the code you pick. Case packs, replacement toppers, the bed, and the mattress are sold separately. Westin Healthcare delivers across Brampton and the GTA.
Specifications
| Model | Span+Aids Surgical and Post-Operative Positioners (not Extremities, not Head and Body, not Heel Manager) |
|---|---|
| Brands | Span America |
| Warranty | Ask for the current Span America term on the code you pick |
| Construction | Medical foam positioners; selected codes vacuum packed for storage |
| Flammability | California Technical Bulletin 117 |
| Intended Use | Site-specific positioning during surgery and after surgery |
| Power | None. Non-powered foam. |
| Care Settings | Acute care, home care, long-term care |
| Default Code | 50642-540 Standard Abduction Pillow, Medium |
| Abduction Size Guide | Under 5 ft: SML. 5 ft 1 in to 5 ft 11 in: MED. 6 ft to 6 ft 5 in: LRG. |
| Standard Abduction Medium | 22 x 14 x 4 x 7 in (50642-540) |
| Abduction Straps | Adjustable Velfoam straps; cotton comfort band on named comfort-band codes |
| Open Heart Kit | 50666-525: 2 leg positioners, 2 heel protectors, 2 leg toppers per kit |
| Ring Diameters | 7 in, 8 in, and 9 in (plus 8 in x 1.75 in ring SP167-000) |
| Ulnar Protector Width | 6 in |
| Type | Body-site specific foam surgical and post-operative positioners |
