Span America F500S Powered Sit to Stand Patient Lift
Span America F500S powered sit-to-stand patient lift with manual base is compact, easy to maneuver and delivers a winning combination of safety, simplicity, and value. F500S sit-to-stand aid is essential for safe, efficient patient transfers between bed, chair and commode. F500S powered sit-to-stand lift features contoured knee pad which is height adjustable. The F500S lift has LCD battery level display; audible low-battery indicator and 2-button pendant with LED indicator. F500S powered sit-to-stand patient lift has manual base which is easily widened with a leg opening lever. An under-bed clearance feature allows use with most low beds.
An essential tool for safe, efficient patient transfers between bed, chair and commode. Compact and easy to maneuver in a variety of settings, the F500S delivers a winning combination of safety, simplicity, and value.
Features
- 500 lb. (228 kg) safe working load
- Easy base width adjustment with locked position; accommodates chairs and commodes.
- Wide non-slip footplate provides stable base for transfer.
- Redundant operation via control unit, allowing use if pendant is lost or damaged.
- Overload protection with visual/audible alert, halts lifting when capacity is exceeded.
- Manual emergency lowering for added safety.
- Quick-release battery can be charged via charging cradle (optional), or via plug-in charger (included) for charging in place.
- Backlit LCD display during operation for ease of viewing.
- Simple, fast assembly using tools provided.
- Certified to:Â ISO 10535;Â IEC/EN/ANSI/AAMI/CAN/CSA-C22.2 60601-1, 60101-1-2, and 60601-1-11; SGS Mark for Safety.
Specifications:
Weight capacity | 500 lbs. |
External base width (closed) | 24.9″ |
Internal leg width (opened) | 33.9″ |
Upright mast height | 40″ |
Overall base length | 37.5″ |
Base Height | 4.9″ |
Min. lifting height with spreader bar | 38″ |
Max. lifting height with spreader bar | 60.5″ |
Knee pad length extension range | 4.5″ |
Max. boom width | 17.7″ |
Net Weight | 111 lbs. |
Shipping Weight | 119 lbs. |
